INFORMACIJA

Prekių grupė
Vikšriniai buldozeriai
Gamintojas / modelis
Shantui SD23
Registracijos metai
2018
Papildomos galimybės
Naujas/nenaudotas
Technikos darbo vieta
jining, Shandong, China
Šalis
Kinija
Bendras įvertinimas
1
2
3
4
5
Mascus ID
AE5844F7

IŠSAMESNĖ INFORMACIJA

Vidinis prekės Nr.
SD23
Paskutinis patikrinimas
yes
Visa aptarnavimo istorija
Taip
Darbinis plotis
373 cm
Gamyklinis numeris
SD23
Bendras svoris
24 600 kg
Ašmenų tipas
Tiesūs ašmenys
Važiuoklė
Vikšrinis
Emisijos klasė
Etapas II
Kabinos tipas
Uždara kabina
Variklis
Cummins NT855-C280S10
Variklio galia
175 kW (238 AG)
Track width
660 mm
Transmisija
shantui
Transporto matmenys (IxPxA)
5870 x 3730 x 3360 mm
Originali spalva
yellow
Padangų gamintojas
Shantui
Informacija apie būklę/Garantija
ISO9001
Likęs priekinių padangų protektorius
100
Gamybos šalis
Kinija
Įrengta
propertynames.pp_equippedfor_2100010
Pristatymo sąlygos
FCA, CPT, FOB, CFR, CIF, EXW
Sertifikatai
GAA, CHI, Nacionalinis Amerikos Standartų Institutas
Priedai
Single ripper/Three-shank ripper
Naudoti priedai
Gervė
Oro kondicionierius
Papildoma hidraulikos sistema
Vieno strypo kaušas
Rodyti daugiau
Kita informacija
Technical Features ●The high power Cummins NT855-C280S10 with high-efficiency turbocharger is equipped to expand the high-efficiency working zone of engine and achieve lower fuel consumption. ●The mature and stable hydraulic torque converter, the high reliability power shift transmission, and two-stage spur gear final drive feature high power transmission efficiency and high durability. ●The engine can run normally and reliably under all load conditions and all hot environments required by the user, without overheating. ●The full box-type main frame features high carrying capacity against impact load and bending moment, in which the application of high performance materials and high strength castings makes the main frame stronger and the high quality welds guarantee the life cycle of the main frame. ●The advanced fuel-saving hydraulic circuit features low energy consumption and convenient maintenances, with the working pressure up to 19.1MPa. ●The integrally injection molded instrument panel features beautiful modeling and realize the automatic diagnosis and whole-process monitoring for the malfunctions in domestic market. ●The chassis system features powerful traction and durability and high adaptability and stability under various complicated working conditions. ●In accordance with ergonomic principles, the gearshift, steering, and accelerator controls are arranged on the left side of the driver, with the adoption of flexible shaft mechanism. The working device controls are centrally arranged on the right side of the driver with adoption of servo control system, featuring light and flexible controls. ●The standard straight tilting blade features powerful cutting force and durability, with optional U-blade at the user’s choice. The single-shank ripper features adjustable penetrating angle and powerful penetrating force, with optional three-shank ripper and traction frame at the user’s choice. Performance Parameters Length × width × height (mm) (excluding ripper) 5528×3725×3741 Operating weight (t)(excluding ripper) 24.6 Engine model NT855-C280S10 Net power/rated speed (kW/rpm) 180/2000 Ground pressure (Mpa) 0.078 Blade type Straight tilting blade U blade Blade capacity(m3) 7.8 for straight tilting blade Applicable Working Conditions Bulldozing, digging, landfill, and other bulk operations.Rodyti daugiau
