Max. kėlimo galia
50 000 kg
Emisijos klasė
Etapas IIIA
Originali spalva
Orange and red
Variklio gamintojas
Weichai Power WP10.375E53
Transporto matmenys (IxPxA)
14.24 m × 2.8 m × 3.82 m m
Pristatymo sąlygos
FOB, CIF
Sertifikatai
GAA, CHI, Techninė apžiūra
Kita informacija
Hip length at full extension
52m
Maximum climbing grade
47%
Maximum speed
9okm/h
Speed parameter
Maximum single rope speed of main winch
145m/min
Full extension of boom/Shorten time
430/450s
Full lifting of boom/Fall time
70/90s
Maximum giant slalom speed
1.8r/min
Weight parameters
Total weight of complete machine
44000kg
Maximum counterweight
10.5t
Dimensional parameters
Overall length of the machine
14240mm
Full width of the whole machine
2800mm
Full height of the whole machine
3820mm
Outrigger span（HorizontalxLongitudinal）
7.4x6.13m
Dynamic parameters
Engine model
WeichaiWP10.375E53(CountryV)
Maximum engine power
276/1900kW/rpm
Maximum output torque of engine
1650/(1200-1600)N·m/rpm
Driving parameters
Maximum travel speed
90km/h
Minimum Turning Radius
12m
Maximum climbing gradient
47%
Angle of approach
17°
Departure angle
15°
Minimum ground clearance
320mm
Humanized control system
The control room can be tilted up to 0-20° to make aerial work more comfortable and safer; the movable counterweight can be freely matched, and the lifting and lowering can be controlled; the mechanical structure is mounted, and the short-distance transportation and unloading are safe and reliable; the machine hangar is streamlined, and the use and maintenance are more convenient.
SMART HYDRAULICSOMPACT DESIGN
Larger flow ensures higher efficiency, like higher speed of wire rope reeling. Shunted mode of independently controlled combined motions realizes higher stability, like simultaneous vibration-free luffing and hoisting.
ELECTRICAL CONTROL
Valves and other hydraulic components realize better inching motion performance. Load-sensing and constant-power techniques optimize fuel efficiency. Simple harness and steady signal transmission. Real-time auto monitoring of operation conditions.
Efficient & Unique Hydraulic System
Triple gear pump, load feedback and constant power control are applied to provide strong lifting capacity and good micro-mobility. Unique steering buffer design guarantees smooth braking operation.
Intelligent Electronic Control
Self-developed controller SYMC special for engineering machinery is configured. The adoption of CAN-bus full-digital network control technology ensures stable control signal, simple harness, and high reliability. Timely feedback of data information can achieve the monitoring of the overall working status in real time.Rodyti daugiau
