XCMG XCT 25

We have all the parts for the machinery:ROCK BUCKET/SKELETON BUCKET /LOOSENING BUCKET/CLEANING BUCKET TILT BUCKET/DITCH BUCKET/BUCKET CLAMP/CLAMSHELL BUCKET/ROTARY SCREEN/CRUSHER BUCKET/RUSHER BUCKET CRUSHING AND SCREENING BUCKET/RAKE/RIPPER/THUMB CLIP/COMPACTION WHEEL Business hours:24 hours, holidays and Sundays Contact: Jason Whatsapp: +86 13675656717 Mobile:+86 13675656717 Wechat:13675656717 Packaging Details 1. Flat frame is more suitable for large construction equipment without disassembly. 2. Containers are the cheapest and fastest. 3. Bulk carriers are more suitable for large construction equipment. 4. Ro-ro shipment is fast and suitable for all kinds of machines. You can choose any mode of transportation according to your needs.

Parameter configuration of XCMG XCT25 crane Lifting capacity Maximum rated lifting capacity (t) : 25 Maximum rated lifting moment (KN.m)1132 Minimum working range (m)3 Maximum lifting height - base arm (m)10.2 Maximum lifting height - fully extended boom (m)41 Maximum lifting height - basic boom + auxiliary boom (m)50.2 Maximum lifting capacity (in tons) : less than 45 tons Boom size Boom length - basic boom (m)10.8 Boom length - fully extended boom (m)42 Boom length - basic boom + auxiliary boom (m)51 Operation speed parameter The maximum lifting speed of the main hoist (m/min) is 135 The maximum lifting speed of the auxiliary hoist (m/min) is 135 The full extension time of the boom (s) is 95 The luffing time of the boom (s) is 35 Rotational speed (rpm)2.5 Engine The chassis engine type SC9DF290. 1 q4 / SC9DF290. 2 q4 Rated power (kw/rpm)213/1900 Driving parameters Maximum driving speed (km/h) : 90 Minimum turning radius (m)21 Maximum climbing gradient (%) : 45 Approach Angle/departure Angle (°)12/14 Minimum ground clearance (mm) : 260 Overall machine specification The total length of the entire machine is 12,870 mm The overall width of the machine (mm) is 2550 The total height of the entire machine (mm) is 3470 Wheelbase (mm) : 4600+1350 Working weight (t)33 Outrigger span Longitudinal × transverse (m)5.65×6.4
