CAT 303.5 E
Kaina be PVM
Spausdinti
INFORMACIJA
Prekių grupė
Mini ekskavatoriai < 7 t
Gamintojas / modelis
CAT 303.5 E
Registracijos metai
2024
Darbo valandų skaičius
500 h
Šalis
Kinija
Bendras įvertinimas
1
2
3
4
5
Mascus ID
1C654A4F
KAINOS
Pasirinkite valiutą
IŠSAMESNĖ INFORMACIJA
Vidinis prekės Nr.
1
Gamyklinis numeris
1
Variklio tipas
Dyzelinis
Paskutinis patikrinimas
2025-06-30
Buvusių savininkų skaičius
1
Važiuoklės būklė
Good Condition
Bendras svoris
3 548 kg
Registracijos numeris
1
Papildomos hidraulinės sistemos pajėgumas
60 l/min
Emisijos klasė
Etapas V
Track width
300 mm
Kaušo talpa
0,12 m3
Transporto matmenys (IxPxA)
4730 x 1780 x 2500 mm
Originali spalva
Original
Kaušo / strypo ilgis
1 260 mm
Variklis
Original
Variklio galia
24,8 kW (33,7 AG)
Variklio gamintojas
Original
Informacija apie būklę/Garantija
1 Year
Gamybos šalis
Jungtinės Valstijos
Pristatymo sąlygos
FCA, FOB, CIF, EXW
Sertifikatai
GAA, CHI
Priedai
We have all the parts for the machinery:ROCK BUCKET/SKELETON BUCKET /LOOSENING BUCKET/CLEANING BUCKET TILT BUCKET/DITCH BUCKET/BUCKET CLAMP/CLAMSHELL BUCKET/ROTARY SCREEN/CRUSHER BUCKET/RUSHER BUCKET CRUSHING AND SCREENING BUCKET/RAKE/RIPPER/THUMB CLIP/COMPACTION WHEEL
Business hours,24 hours, holidays and Sundays
Address: Shanghai City, China
Contact: Jason
Whatsapp: +86 13675656717
Mobile:+86 13675656717
Wechat:13675656717
Email:
Packaging Details
1. Flat frame is more suitable for large construction equipment without disassembly.
2. Containers are the cheapest and fastest.
3. Bulk carriers are more suitable for large construction equipment.
4. Ro-ro shipment is fast and suitable for all kinds of machines.
You can choose any mode of transportation according to your needs.
Naudoti priedai
Surištų vielų dėžė
Oro kondicionierius
Papildoma hidraulikos sistema
guminiai vikšrai
Pjovimo kaušo funkcija
Variklio išankstinis filtras
Kaušas rėtis
Rotating beacon
Diesel heater
Joystick control
Standard digging bucket
Cable bucket
V ditch bucket
Rotator
Kita informacija
Detailed parameters of Carter 303.5E excavator:
Overall machine parameters
The overall dimensions of the machine (length × width × height) and the transportation status are: 4730×1780×2500mm
The wheelbase of the entire machine is 1800mm
The track gauge of the entire machine is 1460mm
The grounding length of the entire machine's track is 2220mm
The width of the entire machine's track plate is 300mm
The height of the entire machine's tracks is 400mm
The height of the entire machine's shoe teeth is 22mm
The turning radius at the rear end of the entire machine: 890mm
The ground clearance of the entire machine: 315mm
The height of the machine's turntable from the ground is 565mm
The width of the turntable of the entire machine is 1780mm
The total width of the entire machine's turntable is 4080mm
The tail end length of the entire machine's turntable is 890mm
The distance from the rotation center of the entire machine to the center of the drive wheel: 780mm
Weight parameter
The overall working weight of the machine: 3548-3770kg
Minimum working weight: 3548kg
Power system parameters
Engine model: Cat C1.8
Rated power (ISO 14396) : 24.8kW
Net power (SAE J1349/ISO 9249) : 23.6kW
Cooling method: Water cooling
Cylinder bore × stroke: 87×102.4mm
Displacement: 1.8L
Performance parameters
Ground pressure: 32.1Kpa
Rotational speed: 9rpm
Bucket digging force: 33kN
Bucket shaft digging force: 18.9kN
Maximum traction force: 31kN
Walking speed: 4.6/2.6km/h
Parameters of the hydraulic system
The maximum flow rate of the main pump is 60L/min
Pressure of the walking hydraulic circuit: 24.5Mpa
Pressure of the rotary hydraulic circuit: 18.1Mpa
Oil capacity parameters
Fuel tank capacity: 46 liters
The capacity of the hydraulic oil tank is 42.3 liters
Engine oil change volume: 7L
Coolant: 5.5L
Operation scope parameters
Maximum excavation radius: 5200mm
Maximum excavation depth: 2880mm
Maximum excavation radius of the shutdown face: 5060mm
Maximum vertical excavation depth: 2320mm
Maximum unloading height: 3520mm
Maximum excavation height: 4920mm
Working device parameters
The bucket volume of the working device: 0.12m³
The boom length of the working device: 2400mm
The length of the working device bucket rod is 1260mm
