Doosan DX 75
Kaina be PVM
Spausdinti
INFORMACIJA
Prekių grupė
Vidutinės galios ekskavatoriai 7-12 t
Gamintojas / modelis
Doosan DX 75
Registracijos metai
2024
Darbo valandų skaičius
600 h
Šalis
Kinija
Bendras įvertinimas
1
2
3
4
5
Mascus ID
27C71847
KAINOS
Pasirinkite valiutą
IŠSAMESNĖ INFORMACIJA
Vidinis prekės Nr.
1
Variklio tipas
Dyzelinis
Buvusių savininkų skaičius
1
Važiuoklės būklė
Good Condition
Paskutinis patikrinimas
2025-07-03
Gamyklinis numeris
1
Bendras svoris
7 420 kg
Variklis
Original
Emisijos klasė
Etapas V
Variklio galia
39 kW (53,0 AG)
Registracijos numeris
1
Variklio gamintojas
Original
Kaušo talpa
0,30 m3
Track width
450 mm
Transporto matmenys (IxPxA)
6030 x 2180 x 2680 mm
Originali spalva
Original
Kaušo / strypo ilgis
1 670 mm
Informacija apie būklę/Garantija
1 Year
Gamybos šalis
Pietų Korėja
Pristatymo sąlygos
FCA, FOB, CIF, EXW
Sertifikatai
GAA, CHI
Priedai
We have all the parts for the machinery:ROCK BUCKET/SKELETON BUCKET /LOOSENING BUCKET/CLEANING BUCKET TILT BUCKET/DITCH BUCKET/BUCKET CLAMP/CLAMSHELL BUCKET/ROTARY SCREEN/CRUSHER BUCKET/RUSHER BUCKET CRUSHING AND SCREENING BUCKET/RAKE/RIPPER/THUMB CLIP/COMPACTION WHEEL
Business hours,24 hours, holidays and Sundays
Address: Shanghai City, China
Contact: Jason
Whatsapp: +86 13675656717
Mobile:+86 13675656717
Wechat:13675656717
Email:
Packaging Details
1. Flat frame is more suitable for large construction equipment without disassembly.
2. Containers are the cheapest and fastest.
3. Bulk carriers are more suitable for large construction equipment.
4. Ro-ro shipment is fast and suitable for all kinds of machines.
You can choose any mode of transportation according to your needs.
Naudoti priedai
Surištų vielų dėžė
Oro kondicionierius
Papildoma hidraulikos sistema
guminiai vikšrai
Variklio išankstinis filtras
Kaušas rėtis
Battery disconnector
Rotating beacon
Diesel heater
Joystick control
Standard digging bucket
Cable bucket
V ditch bucket
Kita informacija
Parameter configuration of Doosan DX75-9C excavator
Specification
Power Traditional Power
Joint venture/import by manufacturers
Bucket backhoe
Tonnage (tons)7
The working weight of the entire machine (kg) is 7420
Bucket capacity (m³)0.3
Boom length (mm) : 3620
The length of the boom (mm) is 1670
Performance
Rotational speed (rpm) : 10.4
The rotational torque (Nm) is 1760
Walking speed (km/h) : High: 4.5 / Low: 2.8
Ground specific pressure (Kpa)34
Bucket digging force (kN)53.4
The digging force of the bucket arm (kN) is 36.9
Power system
Engine model: Yanmar 4TNV98-EXS
Rated power (kw/rpm)39/2200
Displacement (L)6.494
Number of cylinders (4)
Cylinder diameter × stroke (mm)98×110
The working form is straightforward and naturally aspirated.
Hydraulic system
The main pump type is a variable piston pump
The rotary hydraulic motor type is an axial piston motor
The type of walking hydraulic motor is a variable axial piston motor
Control hydraulic circuit (Mpa)3.9
Oil capacity
Fuel tank (L)111
Hydraulic oil tank (L)90
Main body size
Total transportation length (mm) : 6030
The total transportation width (mm) is 2180
The total transportation height (mm) is 2680
The total height of the cab (mm) is 2950
The width of the vehicle is 2130 mm
The grounding length of the track (mm) is 3670
The total length of the track (mm) is 2750
Track plate width (mm) : 450
The total width of the tracks (mm) is 2100
Track gauge (mm) : 1650
The ground clearance of the counterweight (mm) is 1030
Minimum ground clearance (mm) : 370
The minimum turning radius (mm) of the front working device is 1745
The rear end turning radius (mm) is 1750
The maximum height (mm) at the minimum turning radius is 7180
Scope of work
Maximum excavation radius (mm) : 6115
The maximum excavation radius (mm) of the shutdown face is 6270
Maximum excavation depth (mm) : 4080
Maximum excavation height (mm) : 7100
Maximum unloading height (mm) : 7180
Maximum vertical excavation depth (mm) : 2670
Maximum effective excavation depth (mm) : 3725
The width × height (mm) of the bulldozer board is 2100×418
