Hitachi ZX 350
Kaina be PVM
Spausdinti
INFORMACIJA
Prekių grupė
Vikšriniai ekskavatoriai
Gamintojas / modelis
Hitachi ZX 350
Registracijos metai
2023
Darbo valandų skaičius
700 h
Šalis
Kinija
Bendras įvertinimas
1
2
3
4
5
Mascus ID
169EC8DB
KAINOS
Pasirinkite valiutą
IŠSAMESNĖ INFORMACIJA
Vidinis prekės Nr.
1
Variklio tipas
Dyzelinis
Gamyklinis numeris
1
Buvusių savininkų skaičius
1
Paskutinis patikrinimas
2025-07-09
Važiuoklės būklė
Good Condition
Variklis
Original
Bendras svoris
33 700 kg
Variklio galia
202 kW (275 AG)
Variklio gamintojas
Original
Registracijos numeris
1
Emisijos klasė
Etapas V
Kaušo talpa
1,38 m3
Track width
600 mm
Papildomos hidraulinės sistemos pajėgumas
288 l/min
Maksimalus greitis
5 km/h
Transporto matmenys (IxPxA)
11000 x 3190 x 3270 mm
Originali spalva
Original
Kaušo / strypo ilgis
3 200 mm
Informacija apie būklę/Garantija
1 Year
Gamybos šalis
Japonija
Pristatymo sąlygos
FCA, FOB, CIF, EXW
Sertifikatai
GAA, CHI
Priedai
We have all the parts for the machinery:ROCK BUCKET/SKELETON BUCKET /LOOSENING BUCKET/CLEANING BUCKET TILT BUCKET/DITCH BUCKET/BUCKET CLAMP/CLAMSHELL BUCKET/ROTARY SCREEN/CRUSHER BUCKET/RUSHER BUCKET CRUSHING AND SCREENING BUCKET/RAKE/RIPPER/THUMB CLIP/COMPACTION WHEEL
Business hours,24 hours, holidays and Sundays
Address: Shanghai City, China
Contact: Jason
Whatsapp: +86 13675656717
Mobile:+86 13675656717
Wechat:13675656717
Email:
Packaging Details
1. Flat frame is more suitable for large construction equipment without disassembly.
2. Containers are the cheapest and fastest.
3. Bulk carriers are more suitable for large construction equipment.
4. Ro-ro shipment is fast and suitable for all kinds of machines.
You can choose any mode of transportation according to your needs.
Naudoti priedai
strėlės lyno nutrūkimo apsauginis vožtuvas
kaušo strėlės lyno nutrūkimo apsauginis vožtuvas
Surištų vielų dėžė
Oro kondicionierius
Papildoma hidraulikos sistema
Variklio išankstinis filtras
Kaušas rėtis
Battery disconnector
Rotating beacon
Diesel heater
Joystick control
Standard digging bucket
Cable bucket
Ditching/grading bucket
V ditch bucket
Kita informacija
Parameter configuration of Hitachi ZX350 excavator
Specification
The working weight of the entire machine (kg) is 33,700
Bucket capacity (m³)1.38
Boom length (mm) : 6400
The length of the boom (mm) is 3200
Origin: Japan
Tonnage (tons)35
Joint venture/import by manufacturers
Power Traditional Power
Bucket backhoe
Joint venture/import by manufacturers
Power Traditional Power
Performance
Rotational speed (rpm) : 10.7
Walking speed (km/h)3.2/5.0
Climbing ability (%)70/35°
Ground specific pressure (Kpa)68
Bucket digging force (kN)234
The digging force of the boom (kN) is 204
Power system
Engine model: ISUZU AH-6HK1X
Rated power (kw/rpm) : 202/1900
Displacement (L)7.79
Number of cylinders (6
Cylinder diameter × stroke (mm) : 115×125
The cooling method is water cooling
The working mode is direct injection, turbocharging, with intercooler
Hydraulic system
Main pump type variables: Axial piston pump ×2+ gear pump ×1
The maximum flow rate of the main pump (l/min) is 2×288+30.2
The type of walking hydraulic motor is variable axial piston motor ×2
The type of rotary hydraulic motor is axial piston motor ×1
Working hydraulic circuit (Mpa)34.3
Walking hydraulic circuit (Mpa)34.3
Rotary hydraulic circuit (Mpa)32.4
Pilot oil circuit (MPa)3.9
Boom cylinders - Number × cylinder diameter × stroke (mm)146×100
Bucket rod cylinder - number × cylinder diameter × stroke (mm)170×115
Bucket cylinder - number × cylinder diameter × stroke (mm)140×95
Is the hydraulic crushing pipeline standard? No
Oil capacity
Fuel tank (L)630
Hydraulic oil tank (L)180
Engine oil change volume (L)41
Coolant (L)32
Main body size
The total transportation length (mm) is 11,000
The total transportation width (mm) is 3190
The total transportation height (mm) is 3270
The total height of the cab (mm) is 3160
The ground clearance of the counterweight (mm) is 1160
Track grounding length (mm) : 3730
The total length of the tracks (mm) is 4650
Track plate width (mm) : 600
The total width of the tracks (mm) is 3190
Track gauge (mm) : 2590
Minimum ground clearance (mm) : 500
Rear end turning radius (mm)3390
Scope of work
Maximum excavation radius (mm) : 11,100
The maximum excavation radius (mm) of the shutdown face is 10,890
Maximum excavation depth (mm) : 7380
Maximum excavation height (mm) : 10360
Maximum unloading height (mm) : 7240
Maximum effective excavation depth (mm) : 7210
Width × height (mm) of the bulldozer board without a bulldozer shovel
Lifting or deepening with a bulldozer (mm) without a bulldozer
